Bosch Series 8 BID7101B1B, Built-in warming drawer
Design
Programmes/functions
- Touch Control illuminated
- User-friendly electronics: extremely
- easy and comfortable operation
- Easy to clean toughened glass heating plate
- Cavity volume: 54 l
- Loading up to 25 kg
- Can accommodate up to:
- -40plates
- -192 espresso cups
- Temperature control in 4 levels: ca. 30°C – 80°C (glass surface temperature)
- Push-pull opening mechanism
Technical information
- Total connected load electric: 0.82 KW
- Nominal voltage: 220 – 240 V
Performance/technical information
- Appliance dimension (hxwxd): 290 mm x 594 mm x 518 mm
- Niche dimension (hxwxd): 290 mm x 560 mm – 568 mm x 550 mm
- In case of installation under the worktop, installation accessory spare part no. 9001698838 is needed.
- Please refer to the dimensions provided in the installation manual
